This Miller Hi-Speed Head inspires a complete 1929 Ford Model A roadster gow job. Here’s how I’d build it. – David Conwill @Hemmings

Advertisements

Harry Miller was an artist. His preferred medium was race cars—complete race cars built from the wheels up. They cost upwards of $15,000 (almost a quarter-million dollars, adjusted for inflation) and spent most of the 1920s dominating America’s tracks. Unlike such contemporaries as the Chevrolet Brothers, Miller largely kept out of the speed-parts business. He briefly produced a cylinder head for the Ford Model T, but didn’t pursue that market further, supposedly saying “I’m not going to make any more of those heads for the Ford. Those Ford guys don’t have any money anyway!”

In 1929, though, Miller sold his business and retired mere weeks before the beginning of the Great Depression. Unable to stay away, he came back in 1930. Thanks to the terrible economy, however, he had to produce products far less exclusive than his famous racers of the previous decade. One of the things he marketed in conjunction with financial partner George Schofield was an overhead-valve conversion for the Ford Model A. The cylinder head had been sketched up by longtime Miller collaborator Leo Goossen in 1928, shortly after Ford began Model A production.

An overhead-valve (or valve-in-head, as they were often called at the time) design, the Miller head moved both intake and exhaust valves out of the engine block and into the head where the air flow would be freer and more direct to the combustion chambers. The port arrangement was identical to the original Ford, which allowed the stock intake and exhaust manifolds to be used if the buyer desired. The distributor hole was in the same spot as well.

Miller only produced this head very briefly, although Cragar (yes, that Cragar) took over the design and continued it for several more years. Original Miller-Schofield heads like this are a rare find and they still add a lot of pep to a Model A.

All of that is perhaps a long way of saying that a head this special deserves a build to suit. Unfortunately, that’s less common than you’d think. A lot of Model A and T “speedsters” are really just some seats strapped to a stock frame and it seems like when you see OHV conversions for these engines, they’re often on stock-looking closed-cab pickups. All of that is fine and dandy, but it’s not for me.

So lucrative had been the Model T speed-equipment market, makers like Robert Roof jumped into building Model A parts immediately. Image via the HAMB.

Read on

1925 Ford ‘Rajo Special’ Single Seater Engine no. 1704776 – @Bonhams

Advertisements

Really interesting early racer that sold at Bonham’s Quail auction in 2022 for US$50,400 inc. premium

1925 Ford ‘Rajo Special’ Single Seater
Engine no. 1704776

149ci OHV Inline 4-Cyilnder Engine
2 Winfield Model SR Carburetors
Est 50bhp at 3,000rpm
3-Speed Manual Transmission
Leaf Spring Suspension
Rear Mechanical Drum Brakes

*Offered from the Austin Automobile Collection
*Exciting and thrilling early American racecar
*Desirable overhead-valve conversion and double Winfield carburetors
*Striking and period-appropriate livery

EARLY AMERICAN RACERS

The line dividing early race cars from their road-going relatives was often a blurry one. Grand Prix racers were frequently little more than high-end production sports cars shorn of their headlights, while club-level machines were almost without exception based upon typical day-to-day cars. None was more typical than the Model T, and no single model was better catered-to by a burgeoning speed industry than the little Flivver.

Cut-down roadsters and runabouts were the order of the day, though the most serious of amateur and mid-level professional American racers would often go so far as to fabricate entirely new single-seat bodies to fit atop modified chassis. Underneath their customized bodies, early homebrewed race cars employed a variety of ingenious tuning techniques, among the most impressive of which were overhead valve conversions, often with crossflow heads, big, tuned manifolds, and doubled-up carburation.

THE MOTORCAR OFFERED

This 1925 Rajo-Ford Special, to use its full, proper name, employs all these tricks in the pursuit of speed. Sitting improbably low over period Houk quick-release wire wheels, the car’s narrow bodywork conforms closely to its most critical components; namely the driver and the Rajo OHV crossflow cylinder head-equipped engine at their command.

Quite exotic and rare pieces of historic speed equipment in any form, Rajo OHV conversions were known to nearly double factory Ford Model T horsepower figures (to just shy of 40). The example fitted here is particularly special for its crossflow configuration, in which intake and exhaust valves are situated perpendicular to the axis of the crankshaft, allowing for drastically improved engine breathing, and netting equally enhanced throttle response, higher revving, and greater power output.

Dual Winfield race carbs ride like jewelry atop an impressively vertical intake manifold and help lead the driver’s eye toward a period moto-meter radiator temp gauge. Inside the slender, cigar-shaped bodywork and mounted to a wooden dashboard are a rare era-correct Motorola mechanical tachometer and controls for an aviation magneto, while gear changing is now achieved through a lever sprouting up between the driver’s legs.

Lever-action shock absorbers have been added to assist standard Ford transverse leaf springs front and rear, and should bring tangible improvements to the car’s ride and road holding.
Viewed at any angle, the Rajo-Ford Special exudes lean athleticism and fitness for purpose, from narrow nose to bobbed boattail, possessing an elegance of line and engineering equal to the finest purebred sports machines of the time.

Ford Model T Buyers Guide (1908 – 1927) – carphile.co.uk

Advertisements

In this carphile.co.uk video a UK Ford Model T specialist discusses what they look for when buying a Model T, giving hints and tips about what you should look for when buying one of these cars.

Richard Rimmer is the owner of Model T Ford Specialist, The T Service, based in Weston on Green in Oxfordshire, UK. http://www.tservice.co.uk/index.html

The Ford Model T was in production from 1908 to 1927, it mobilised the US middle class and is today the car credited with putting America on wheels. Over 16 million were produced in nearly two decades and with many Model T parts either re-manufactured or available second-hand, the Model T is probably one of the easiest veteran/vintage cars to own and drive in the 21st century.

DISCLAIMER: This video and the information within it is intended for guidance purposes only. Neither carphile.co.uk or The T Service Ltd shall be under any liability in respect of any information/views contained within this video. Please be advised to always consult a qualified specialist before making a decision to buy a car. Find out more about Ford vintage, classic and sports cars and other interesting classic and modern cars at http://carphile.co.uk

FIRE IN THE HOLE! Mighty Model “T” Race cars along with a Brief History of the Sport in Alberta – Strong’s Garage

Advertisements

Found these guys on YouTube, excellent vintage stuff!

Gentlemen Start your Engines! We’ll take a tour of two barn find survivor race cars from Alberta’s Racing Past. Take a gander at the ingenious modifications that turn these Tepid T’s into Fire Breathing Dragons!

Knowing when to walk away: Why I decided not to build my 1921 Ford Model T and what I’ll do instead – David Conwill @Hemmings

Advertisements

*Tilly came home on a trailer, but as of this writing is already a running and driving car. She just needs some help to be ready for the roads of her second century.*

Last night, I decided I can’t continue with my Model T project. It’s a tough decision. I’ve wanted a Model T touring car since I was about eight years old (that’s 30 summers now) and I’ve now owned two different touring car bodies and a complete car. I’ve tried really, really hard to make a Model T happen, but it never seems to work out.

If you’ve been following my columns, you know that I’ve been planning to rebuild my ’21 into an early-1930s style hot rod, called a gow job. I’ve wanted a gow since I first learned that hot rodding predated World War II—those cars look awesome and because they’ve got improved power, handling, and braking, they’re a lot more usable than a purely stock 1920s car.

Nevertheless, I’m an adult and not independently wealthy. It’s tough enough to have three kids, a house, and two cars for transportation. A purely “fun” car is great but it would be an irresponsible avenue to continue pursuing–I’ll live off ramen to fund a project, but I won’t ask my family to do that. We have more practical needs to look after first. In fact, I’ll be putting my Model T and parts up for sale soon and putting that money into the home-improvement fund

*Our ’08 Charger police car. It has 350 horsepower when it isn’t shutting down cylinders at random. That’s my old ’62 Falcon behind it.*

This doesn’t mean I’m done with old cars, though. Far from it. It just means that I’ve got to rethink my driver situation. Our current fleet consists of a 2008 Dodge Charger police car and a 1983 Cadillac Sedan de Ville. The Charger we’ve had for five years, and while it’s fun to drive, it has an increasing number of electrical maladies and has been spending a lot of time in the shop. Once it’s fixed, it can find a new home with someone who enjoys working on late-model Mopars.

The Cadillac we got just last week. It is very cool but I can’t see us keeping it—it’s too nice. That sounds weird, but the biggest problem with the Cadillac is that it was purchased new by my wife’s grandfather the same year she was born. A car with that level of sentimental value is something of a white elephant in and of itself. It only has 23,000 miles on it and it’s a perfectly preserved cream puff. Putting wear and tear on it would be heartbreaking, and fixing all the luxury features as they age would be an utter nightmare. Instead, I intend to polish it up (I’ve been spending a lot of time researching paint care), tune it up, and try to find it a good home before the end of the summer.

Read on

How I plan to make my 1921 Ford Model T more capable, starting with chassis and brake upgrades – David Conwill @Hemmings

Advertisements

It’s weird to think I own a car that is 99 years old. Of course, if we do things correctly, it will be like owning a car that’s only 86. That’s right: I’m updating my 1921 Ford Model T touring car with the best of 1934 technology, or at least “the best” insofar as updating a Model T is concerned.

One of the wheels just before I shipped it out to Clayton. It’s 19 inches, as used on a 1930 or ’31 Chevrolet. The 1932 Ford Model B hubcap fits like it was made for it.

I could get into an extended explanation of why people modified Model Ts extensively once their ubiquity was established, and I could tell you all about my belief that performing period-correct modifications makes the Model T far more usable on 21st-century roads without sacrificing its historical character.

Let’s save that for another time, though. Let’s discuss the how.I sat down on Saturday, November 28, for what ended up being a three-hour conversation with Clayton Paddison about the modifications planned for my T. Clayton has been a good friend of mine for probably 10 years now.

This is a kit to install external-contracting Rocky Mountain brakes on a 1926-’27 Ford rear axle. The bands (which will be re-lined with an improved friction material) grab the outside of the 11-inch parking-brake drums. The kit was manufactured in the 1990s and never installed.

His jaw-dropping 1927 roadster is, for many, the quintessential modern gow job (defined briefly as an early-1930s style hot rod). Clayton has a full-time job and as also runs Paddison Pre-War and Model T.

He’s also dad to three. When he offered to devote some of his precious time to shepherding the heavy lifting on my Model T build, I gratefully took him up. I’m a lot better with a pen or a camera than I am with fabricating.Earlier this year, Clayton spotted a great deal on a touring car locally and suggested I jump on it as a shortcut to having a T sooner than my original plan to build from parts.

I was able to make it happen, but almost to our dismay, what appeared initially to be an older restoration seems to mostly be an original. We amended our initial, rather aggressive plans for modification in favor of something more suited to preserving the surviving originality of my car. The new plan, I feel, makes for a car that will be capable of any driving I may want from it and still has the early ’30s gow-job feeling I want to experience

Read on

How I plan to upgrade the engine, transmission, rear axle, and driveline on my 1921 Ford Model T – David Conwill @Hemmings

Advertisements

‘ve been nattering about this project for a few years now, as the plans have morphed based on my resources. Last month, I unveiled the first installment in a series of articles discussing, in depth, the recipe I’ve worked out with my friend Clayton Paddison to turn a well-preserved 1921 Ford Model T touring car into something capable of running on modern roads without hanging an orange triangle on the back.

The blueprint we’ve laid out uses 1920s and ’30s technology to expand the capabilities of the Model T’s 1900s design in much the same way a driver in that era might have done so. The previous installment dealt with the chassis and brakes. This month, I want to explain our plans for the powertrain: engine, transmission, rear axle, and driveline.

Engine

The engine on a hot rod should never be an afterthought, yet on my car it’s getting only mild attention. That’s because it’s an original, 99-year-old (June 1921) engine that still runs well.

I know that if I were to start hotting it up, it would quickly collapse under the strain. On a pre-1927 Model T engine (engines stayed in production through December 1941), the biggest weakness is the “bent-paperclip” crankshaft.Eventually, when the reservoir of fun tickets has refilled, I will build the “big” engine—starting with a 1926-’27 block and EE-series crank and capped off with a pair of Stromberg 81s on an Evans intake. Beyond that, who knows? Maybe by then I’ll have acquired the Rajo Model A head I’ve always wanted.

Alternately, I’ve also got a ’28 Chevrolet head bumping around here that I can’t bear to part with.Until then, a set of aluminum pistons and a few mild bolt-ons will suffice. The original intake manifold and Kingston L4 will be set aside and replaced with a “straight-through” Holley NH and an aftermarket high-volume intake manifold.

The straight-through NH was a short-lived version of the common Model T carburetor that flows slightly better than the norm and the high-volume intake is a necessity to take advantage of its potential.Bigger, one-piece valves and a high-lift camshaft will further the performance enhancements, permitting more mixture into the cylinders.

To make sure that charge is properly tumbled and squeezed, I’ve also sent Clayton an aluminum “Z” Head which has about 6:1 compression (stock was 4.5:1—gas wasn’t great in the ’20s—and the practical maximum for an L-head engine is around 7 or 7.5:1, but that’s awful hard on the bottom end of a stockish T engine) and the efficient combustion chambers advocated by the great Harry Ricardo.

Read on

October 1, 1908: Pass Me? Not a Chance — Reblog from Wretched Richard’s Almanac

Advertisements

Automobiles had been around for decades as we entered the 20th century but they were scarce and rather pricey. That was about to change. On October 1, 1908, a new sort of vehicle hit the streets. Known variously as the Tin Lizzie, Leaping Lena or the Flivver, the Ford Model T was the people’s car, […]
October 1, 1908: Pass Me? Not a Chance — Wretched Richard’s Almanac

October 1, 1908: Ford Motor Company unveils the Model T, the “car of the century“ — Reblog from RANDOM Times

Advertisements

Hailed as “the car of the century,” the first Model T Ford rolled off the assembly line in Detroit, Michigan, on this day, October 1, 1908. One of the leading executives behind the project, Charles E. Sorensen, was to describe later the eventful day when Henry Ford announced the idea. In his book, “My Forty […]
October 1, 1908: Ford Motor Company unveils the Model T, the “car of the century“ — RANDOM Times •

Clayton Paddison’s 1927 Model T

Advertisements

For one so young Clayton has made a real splash in the Model T and particularly the hot rod aspects. Not everyone can build a T that cruises at 65mph for under $7K!

Clayton came back to my attention recently in a David Conwill article in Hemmings, where David described how Clayton will be helping him with his T

Going back a few years Clayton and his T were featured in an episode of Jay Leno’s garage

Jay enjoyed the experience so much that he ended up visiting Clayton in Oregon

You can see the article here

Clayton’s build blog can be found on the Model T Ford Forum

First Start

Engine spec

’26-’27 block, bored .080 over
’26-’27 “EE” series crank
Egge .080 pistons
.300C full-race cam
289/302 Ford SB V8 valves
New babbit bearings (rods/mains)
fully balanced engine/transmission

Chicago Transmission
